VD500 FILLING MACHINE

Machine specifications:

• The machine is a volumetric filling machine operating with a pneumatic system.

• It draws the product from an 80-liter hopper, featuring either standard or level control systems depending on requirements.

• Weight (dosage) adjustment is easily set and recorded using a handwheel and a counter.

• It draws the product to be filled directly from its own hopper or can be connected underneath the production tank for direct feeding.

• High surface smoothness and argon welding technology prevent bacterial growth and contamination.

• Sealing elements are manufactured from Teflon, Viton, or Polyethylene materials, depending on the chemical properties and temperature of the material to be filled.

• Parts on the machine are connected to each other using tri-clamps.

• The nozzle, valve, and filling piston are designed for easy cleaning and can be disassembled without the use of tools.

• Interchangeable filling nozzles are available for liquid, viscous, or granular products.

• There is a drawer-type platform for placing packaging during the filling process; this platform is height-adjustable to accommodate different container sizes.

• The machine is mounted on a stainless steel frame supported by 4 wheels, allowing it to be moved and prepared for operation quickly in any location.

• Both tabletop and wheeled models are available.

• The machine operates on 6 bar (ATÜ) compressed air; no electrical or electronic systems are utilized (except for stirrer and heated hopper systems).

• Detailed user manuals are provided for each model.

Materials used in the machine:

• All surfaces in contact with the product are made of 316 L grade stainless steel. Other external surfaces, protective covers, and legs are made of 304 grade stainless steel and aluminum.

• FESTO brand pneumatic equipment (oil-free system).

Operating temperature:

Filling can be performed from 5 ºC to 85 ºC with standard sealing gaskets, and above 90 ºC with gaskets made of special materials.

Filling accuracy: ± 1%

Fillable products:

Jam, Chocolate Cream, Marmalade, Ketchup, Mayonnaise, Tomato Paste, Mustard, Appetizers, Olive Paste, Pastry and Food Sauces, Honey, Tahini, Molasses, Liquid Sauces, Olive Oil, Pomegranate Sour, Vinegar, Turnip Juice, Milk, Ayran, Kefir, Boza, Fruit Juice, etc. Suntan Oil, Nail Polish, Acetone, Vegetable Oils, Massage Oils, Cologne, Perfume, Shampoo, Liquid Soap, Cream, Lotion, Mask, Hair Conditioner, Hair Dyes, Mud, Vaseline, etc. Thinner, Glue, Liquid Agricultural Pesticides, Mineral Oil, Auto Chemicals, Antifreeze, Ink, Liquid Dish Soap, Paint, Silicone, Epoxy, Grease, Shoe Polish, etc.
